工况环境下振动对波纹管疲劳性能的影响

详细信息

Effect of Vibration on Fatigue Performance of Bellows under Working Conditions

摘要: 研究了热网波纹管在工作应力、工作介质及工作温度等工况环境下系统振动对其疲劳性能的影响,采用显微组织分析、硬度分析、SEM分析等手段对波纹管的失效情况进行了分析。结果表明:波纹管的疲劳裂纹从内、外表面两侧起裂,并向材料中心方向扩展至尖端相近时,发生瞬断,裂纹相接处呈韧性断裂。工况环境下振动对波纹管残余应力起到了一定的消除作用,并显著提升了波纹管的抗疲劳性能。
- 波纹管 /
- 疲劳性能 /
- 振动
Abstract: Here is studied the influence of system vibration on the fatigue performance of bellows for thermal networks under working conditions like working stress, working medium and working temperature. The failure of the bellows is analyzed by means of microstucture analysis, hardness analysis and SEM. The results show that the fatigue crack of the bellows initiates from the inner and outer surfaces, and when it expands to near the tip of the crack along the direction to the center of the material, the below fractures instantly. The joint fracture shows ductile morphology. Under the working condition, the vibration has a certain effect on eliminating the residual stress of the bellows, and can significantly improve the fatigue properties of the bellows.
- bellows /
- fatigue performance /
- vibration

[1]	魏翔云,敬和民,郑玉贵,等.热力管线中不锈钢波纹管破裂原因分析[J].腐蚀科学与防护技术, 2002, 14(6):365-367.
[2]	杨帆,孙智,马景涛,等.供热管道波纹管补偿器的腐蚀失效[J].煤气与热力, 2005, 25(6):13-16.
[3]	于雅泽,李晓恭.基于ANSYS的供热管道系统振动分析及改造[J].煤气与热力, 2011, 31(9):12-14.
[4]	王乐勤,何秋良.管道系统振动分析与工程应用[J].流体机械, 2002, 30(10):28-31.
[5]	刘晓丹,陶兴华,韩振强.振动时效工艺在消除膨胀波纹管残余应力中的应用[J].振动与冲击, 2015, 34(4):171-174.
[6]	顾邦平,胡雄,徐冠华,等.基于位错密度演化的高频振动时效微观机理[J].稀有金属材料与工程, 2018, 47(8):2477-2482.
[7]	沈国鉴,李敏,薛新.金属波纹管流固耦合动态特性分析与试验研究[J].兵器材料科学与工程, 2020, 43(5):36-42.
[8]	罗宏瀚.输流波纹管流固耦合振动的初步研究[J].振动与冲击, 2008, 27(11):149-153.
