Properties of Flame Retardancy and Low Toxicity of Siloxane Modified Vinyl Ester Resin Composites
-
摘要: 对玻璃纤维增强的硅氧烷改性乙烯基树脂复合材料的成型工艺及力学、阻燃低毒性进行研究。研究发现,对厚度小于40 mm的层合板,使用一次成型的真空辅助成型工艺即可获得较好的形态,而厚度大于40 mm的层合板需使用二次成型方法。改性后的复合材料力学性能下降幅度在10%左右。从氧指数、低播焰、烟毒性、常温毒性、高温毒性等方面,对硅氧烷改性的乙烯基树脂复合材料的阻燃性和毒性进行研究,结果表明,磷、硅协同阻燃作用显著提高了该复合材料的阻燃性能,其氧指数从24.5%提高到38.0%,其低播焰性能够满足墙壁和天花板衬板的使用条件;硅氧烷化合物的低毒、低烟特性显著降低了该复合材料的烟毒性,其最大烟密度为189,毒性为低等毒性,满足密闭环境的使用要求。
-
关键词:
- 硅氧烷改性乙烯基树脂 /
- 真空辅助成型 /
- 力学性能 /
- 阻燃性能 /
- 低毒性能
Abstract: The forming process, mechanical property, flame retardancy and low toxicity of the glass fiber reinforced siloxane modified vinyl resin composites are studied. It is found that when the thickness of the laminate is less than 40 mm, the composite material can be formed by vacuum assisted resin infusion(VARI) in the primary forming, and the formation is fine. When the thickness of the laminate is more than 40 mm, the composite material can be formed by VARI in the secondary forming. The mechanical properties of the modified composites decrease by less than 10%. The properties of flame retardancy and low toxicity of the siloxane modified vinyl resin composites are studied by oxygen index, low flame seeding, smoke toxicity, normal temperature toxicity and high temperature toxicity tests. The results show that the synergistic flame retardancy of the phosphorus and silicon significantly improves the flame retardancy of the composite, and that the oxygen index increases from 24.5% to 38.0%. The low flame retardancy can meet the service conditions of the wall and ceiling lining. The low toxicity and low smoke properties of the siloxane compounds significantly reduce the smoke and toxicity of the composites. The smoke density of the siloxane modified vinyl resin composites is 189, and its toxicity is low, which can be used in a closed environment. -
-
[1] 曾汉民.高分子复合材料的进展:纤维增强树脂基复合材料(续)Ⅱ.纤维增强材料和纤维增强热固性树脂复合材料[J].材料工程, 1989, 17(6):8-20. [2] TANAKA K, CHUJO Y. Advanced functional materi-als based on polyhedral oligomeric silsesquioxane (POSS)[J]. Journalof Materials Chemistry, 2012, 22(5):1733-1746.
[3] WALCZAK M, JANUSZEWSKI R, FRANCZYK A, et al. Synthesis of monofunctionalized POSS through hydrosilylation[J]. Journal of Organometallic Chemistry, 2018, 872:73-78.
[4] YE M F, WU Y W, ZHANG W C, et al. Synthesis of incompletely caged silsesquioxane (T7-POSS) compounds via a versatile three-step approach[J]. Research on Chemical Intermediates, 2018, 44(7):4277-4294.
[5] 陈达,高东静.笼型倍半硅氧烷(POSS)的应用进展研究[J].现代化工, 2015, 35(4):21-24. [6] 王占彬,冷世伟,范金娟,等.八苯基笼型倍半硅氧烷的官能化及其在高分子纳米复合材料中的应用[J].高分子通报, 2011(9):63-70. [7] 何辉,袭锴,葛仁杰,等.笼型倍半硅氧烷(POSS)的合成及应用进展[J].高分子材料科学与工程, 2008, 24(4):5-9. [8] 康永.笼型倍半硅氧烷改性树脂的性能分析[J].上海塑料, 2011(4):12-15. [9] 韩旭,张晓华,张松利,等.含磷氮POSS改性乙烯基树脂的阻燃性和热性能研究[J].化学通报(印刷版), 2021, 84(10):1066-1073. [10] 邱武辉.POSS基含磷嵌段共聚物的合成与无卤阻燃环氧树脂的研究[D].厦门大学,2014. [11] 郝玉秀.含羟基POSS的合成及其改性硅树脂耐热性的研究[D].哈尔滨:哈尔滨工业大学, [12] 邱求元. POSS改性环氧树脂及其热性能与流变行为研究[D].长沙:国防科学技术大学, 2007. [13] 宋冉冉. POSS改性环氧树脂及复合材料性能研究[D].哈尔滨:哈尔滨工业大学, 2019. [14] 金晶,安秋凤,杨博文,等.环氧基POSS改性环氧树脂的研制与性能研究[J].化工学报, 2020, 71(5):2432-2439. [15] LIU B B, WANG H L, GUO X Y, et al. Effects of an organic-inorganic hybrid containing allyl benzoxazine and POSS on thermal properties and flame retardancy of epoxy resin[J]. Polymers, 2019, 11(5):770.
[16] CHRU Ś CIEL J J, LE ŚNIAK E. Modification of ep-oxy resins with functional silanes, polysiloxanes, silsesquioxanes, silica and silicates[J]. ProgressinPoly-mer Science, 2015, 41:67-121.
[17] 袁刚,饶秋华. POSS的合成及其在环氧树脂改性中的应用进展[J].材料开发与应用, 2014, 29(5):104-112. [18] 中国国家标准化管理委员会.纤维增强塑料拉伸性能试验方法:GB/T 1447-2005[S].北京:中国标准出版社,2005. [19] 中国国家标准化管理委员会.纤维增强塑料弯曲性能实验方法:GB/T 1449-2005[S].北京:中国标准出版社,2005. [20] 中国国家标准化管理委员会.纤维增强塑料燃烧性能实验方法-氧指数法:GB/T 8924-2005[S].北京:中国标准出版社,2005. [21] 国际海事组织海上安全委员会.2010年国际耐火试验程序应用规则第5部分表面可燃性实验[S].北京:人民交通出版社,2011. [22] 国际海事组织海上安全委员会.2010年国际耐火试验程序应用规则第2部分烟气及其毒性测试.北京:人民交通出版社,2011. [23] MORGAN A B, GILMAN J W. An overview of flame retardancy of polymeric materials:application, technology, and future directions[J]. Fire and Materials, 2013, 37(4):259-279.
[24] LIU Y, WANG Q. Melamine cyanuratemicroencapsulated red phosphorus flame retardant unreinforced and glass fiber reinforced polyamide 66[J]. Polymer Degradation and Stability, 2006, 91(12):3103-3109.
[25] XUT C, ZHANGL F, CHENGZ P, et al. A novel m-ethacrylate with a bisphosphonate group:raft polymerization and flame retardant property of the resultant polymers[J]. Polymer Chemistry, 2015, 6(12):2283-2289.
[26] 许一婷,王华进,王子超,等.阻燃剂多尺度结构设计与绿色火安全材料研发[J].厦门大学学报(自然科学版), 2021, 60(2):247-262. [27] MARTÍN C, LLIGADAS G, RONDA J C, et al. Synthesis of novel boron-containing epoxy-novolac resins and properties of cured products[J]. Journal of Polymer Science Part A:Polymer Chemistry, 2006, 44(21):6332-6344.
