多孔橡胶制品注射成型的硫化模拟与实验研究

徐鲁杰; 陈玉虎; 张玲; 黄明; 翟孟雷; 陈文广

多孔橡胶制品注射成型的硫化模拟与实验研究

1. 海军装备部驻洛阳地区某代表室, 河南洛阳 471023;
2. 郑州大学橡塑模具国家工程研究中心, 河南郑州 450002;
3. 中国船舶集团有限公司第七二五研究所, 河南洛阳 471023

详细信息

作者简介:
徐鲁杰,男,1982年生,硕士,工程师,主要从事机械自动化技术研究。E-mail:18737930028@139.com

通讯作者:
张玲,女,1983年生,硕士,高级工程师,主要从事非金属减震降噪材料研究。E-mail:zhangling918813@163.com

中图分类号: TQ330.67
计量
- 文章访问数: 144
- HTML全文浏览量: 49
- PDF下载量: 14
出版历程
- 收稿日期: 2023-05-18
- 网络出版日期: 2024-01-09
- 刊出日期: 2023-12-14

Simulation and Experimental Study on Injection Molding Vulcanization of Porous Rubber Products

1. The Navy Representative Office in Luoyang, Luoyang 471023, China;
2. National Engineering Research Center for Advanced Polymer Processing Technology, Zhengzhou University, Zhengzhou 450002, China;
3. Luoyang Ship Material Research Institute, Luoyang 471023, China

摘要

摘要: 基于实验测试及丁腈橡胶材料注射成型模型的拟合参数，以及结合充填阶段胶料硫化和温度场的变化情况，对厚壁多孔橡胶制品注射成型的硫化过程进行模拟。分析了不同充填条件对保压硫化阶段模拟的影响，并通过实验验证模拟结果的准确性。
- 注射成型 /
- 模型拟合 /
- 丁腈橡胶 /
- 厚壁多孔橡胶
Abstract: Based on the experimental testing and fitting parameters of the injection molding model of the nitrile rubber material, and combining the change of the rubber rulcanization and temperature in the filling stage, the vulcanization process of thick-walled porous rubber is simulated. The influence of different filling conditions on the simulation of pressure holding vulcanization stage, and the the accuracy of the simulation is verified through relevant experiments.
- injection molding /
- model fitting /
- nitrile rubber /
- thick-walled porous rubber
